The WSS430 flagship maintains its siblings shallow depth all three feature identical footprints and offers supreme audio performance, drawing on design principles, and materials, from Monitors Audios high-end Platinum II speakers.
The WSS430 range topper employs dishedcones to ensure ultimate diaphragm rigidity the main aim here is to reduce distortion. High strength Neo magnets and larger voice coils provide incredible driving force, low magnetic leakage, and slim profile. The magnetic system provides an under-hung motor arrangement, ensuring the coil stays in the gap, reducing distortion further and increasing power handling.
Still just 50 mm deep, there is a lot going on with the WSS430. Thehigh frequency transducer technology also from Monitor Audios flagshipdesigns ensures incredibly low distortion, delivering clear high frequency to over 50 kHz. Remove the models magnetic front trim and you can rotate the tweeter to provide the optimum dispersion when using the model in landscape orientation.
Key Features:
- Good, better, best performance levels
- Super-slim depth 50 mm (2") designed to fit in 2" stud walls or where space is restricted
- Designed for portrait or landscape installation fits between standard 14" stud bays
- Elegant, slim profile only 385 x 140 mm wide
- Three, 3" bass/mid-range drivers featuring incremental technology and performance benefits ,and dished C-CAM cones
- 25 mm C-CAM Gold Dome tweeter used on WSS130 and WSS230 models. WSS430 utiliseshigh frequency transducer from Platinum IC model and flagshipspeaker range
- High quality crossover components Selected and voiced for amazing sonic performance
- Magnetically attached trim-less grille discreet, reliable, and easy servicing
- Dog leg fixings reliable, robust, and quick to install
- Gold plated sprung push terminals easy to connect and reliable
- Paintable grille to complement and blend with dcor
- WSS430 has rotating tweeter for optimum dispersion when used in landscape configuration
- (dark blue) pre-construction bracket
Product Video:
Specifications:
| Frequency Response (-6 db) | 70 Hz 50 kHz |
| Nominal Impedance | 8 Ohms |
| Sensitivity (1 W @ 1 m) | 87 dB |
| Maximum SPL | 105.6 dBA |
| Power Handling (RMS) | 75 W Full Range (120 W with Crossover set to 100 Hz @ 12 dB/Octave) |
| Recommended Amplifier Requirements | 10 120 W |
| Drive Unit Complement | 3 x 3" Dished C-CAM Cone Bass-Mid Drivers, 1 x MPD High Frequency Transducer Rotatable for Portrait or Landscape Application |
| Crossover Recommendation Using AVR/Processor | 100 Hz at a Minimum of 12 dB/Octave (24 dB/Octave Optimum) |
| Overall Dimensions (Including Grille) | 385 x 140.5 mm (15 x 5 1/2") |
| Overall Depth (Including Grille) | 54.25 mm (2 1/8") |
| Mounting Depth | 50 mm (2") |
| Cut-Out Dimensions | 346 x 101 mm (13 1/2 x 4") |
| Connection | Gold Plated Sprung Push Terminals For Bare Wire Connection up to 3 mm2 |
| Fixing Type | 6 Position Tri-Grip Dog Leg Fixings |
| Construction Material | Mineral Filled ABS Plastic, RoHS 2 Compliant. Painted Steel Grille |
| Weight | 1.1 kg (2 lb 6 oz) |
| Pre-Construction Bracket | WB3 Pre-Construction Bracket (Dark Blue) |
