This medium-sized Tier 1 in-wall loudspeaker is a two-way model featuring two C-CAM mid-bass drivers and a C-CAM tweeter. It has a cut-out dimension of 527 x 198mm and revolutionary patented Quick-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.
Key Features:
- Ideal for cost-effective installations, where product simplicity and solid acoustic performance is required
- Two-way design
- 1 x 1"(25 mm) C-CAM tweeter with UD Waveguide I for lifelike sound
- 2 x 5" (127 mm) C-CAM mid-bass driver for clear mid-range and full bass
- Patented Quik-Link speaker cable connector for quicker installation(UK patent application no. 2216966.8)
- Tri-Grip II for easy and secure fitment
This medium-sized Tier 1 in-wall loudspeaker is designed for cost-effective installations, where product simplicity and solid acoustic performance is required. It is a two-way model featuring a C-CAM mid-bass driver and C-CAM tweeter. The performance benefit of having both within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear lifelike high-fidelity sound of the quality youd expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 527 x 198 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.
Specifications:
| Drive Units Complement | 2 x 5 C-CAM bass driver, 1 x 25mm C-CAM tweeter |
| Nominal Impedance | 6 Ohms |
| Amplifier Requirement | 30 - 110 W |
| Continuous Power Handling | 75 W |
| Sensitivity (2.83v @ 1m): | 85 dB |
| Cut Out Size | 527 x 198 mm |
| Mounting Depth | 85 mm |
| Dimensions | inc. grille: 540 x 211 x 90 mm (21 1/4 x 8 5/16 x 3 9/16) |
| Weight | 3.4 kg (7 lb 8 oz) |
