Summary
50W x 4 300W (4)
75W x 4 500W (2)
150W x 2 (Bridged) 300W (4)
* Conformal Coating: Do not install the unit in a spot exposed to direct sunlight or excessive heat or humidity. Also avoid places with too much dust or the possibility of water splashing.
Overview
CEA-2006 Primary Ratings | Power Output | 50 Watts RMS x 4 300 Watts RMS x 1 at 4 Ohms and 1%THD N |
|---|---|---|
| Signal-to-Noise Ratio | 80dBA (Reference: 1Watt into 4Ohms) | |
Maximum Power Output | MAX POWER | 1600W |
Rated Power Output at 14.4V | A/B (4 Ohms) | 50Watts RMS x 4 (4 Ohms, 20-20kHz, 1.0% THD) |
| A/B (2 Ohms) | 75Watts RMS x 4 (2 Ohms, 1kHz, 1.0% THD) | |
| SUB (4 Ohms) | 300Watts RMS x 1 (4 Ohms, 20-200Hz, 0.5% THD) | |
| SUB (2 Ohms) | 500Watts RMS x 1 (2 Ohms, 100Hz, 0.5% THD) | |
| A/B (Bridged 4Ohms) | 150Watts RMS x 2 (Bridged 4 Ohms, 1kHz, 1.0% THD) | |
Specifications | Signal to Noise Ratio | 100dB (Reference: Rated Power into 4Ohms at 14.4V) |
| Frequency Response | 20Hz-50kHz ( 0dB, -3dB) A/B 20Hz-200Hz ( 0dB, -3dB) SUB | |
| Input Impedance | 10k ohm | |
| Speaker Impedance | 4 (2 to 8 allowable) | |
| Bridged Connection | 4 to 8 allowable | |
Audio Section | Low-Pass Filter | 50Hz-200Hz, -24dB/oct (SUB) |
| High-Pass Filter | 50Hz-200Hz, -12dB/oct (A/B) | |
| Bass Boost | 40Hz, 0dB - 18dB (SUB) | |
| RCA Input Sensitivity | 0.2[V] - 5.0 [V] | |
| Speaker Level Input Sensitivity | 4.0[V] - 12.0 [V] | |
Terminals | Battery & Ground | M6 Screw Type Terminal Block |
| Speaker Output | M4 Screw Type Terminal Block | |
General | Dimensions(WxHxD) | 9 x 2-3/16 x 7-3/8 [inch] |
| Operating Voltage | 14.4V11-16V allowable | |
| Current Consumption | 58[A] | |
Key Features | CEA-2006 Compliant 2 Ohms Load Capability Speaker Level Input with Signal Sensing Turn-on Power MOS-FET Switching Power Supply Extruded Aluminum Heat Sink Design A B Sub Independent Gain Adjustment | |
