Today the world is busy; fast and full of noise.

We know the power of music, and how its capable of taking you out of this world and someplace new. Somewhere tranquil, where melodies can uplift, and vocals can move you to tears. Our new DAC, with its sleek design and unparalleled performance, immerses you in a world of pure harmony. Rediscover your music, and be transported to purity, with the ZEN DAC 3.

Key Features

• Ultra res audio: PCM 768kHz, DSD 512 and Full MQA Decoding
• USB-C input for plug and play connectivity
• Fixed or variable output gain for optional preamp functionality
• Improved DC offset and USB-C input overvoltage protection
• 4.4mm balanced headphone and line outputs
• XBass and PowerMatch analogue processing modes

Hi-Res Heaven

ZEN DAC 3 supports all PCM formats up to 768kHz , DSD natively supports up to DSD 512, and even offers full MQA decoding.

Your Way or the Hi-Way

Offering both fixed and variable output gain options, ZEN DAC 3 can seamlessly connect to headphones, an amplifier or active speakers.

Beautifully Balanced

ZEN DAC 3 features two 4.4mm balanced outputs , one for headphones and one for other amplifiers , effectively minimizing distortion and crosstalk.

DACtivate your Speakers

Variable or Fixed output switch, which enables/bypasses the volume knob.

• Use Variable mode when plugging ZEN DAC 3 directly to active speakers.
• Use Fixed mode when running line outputs to a receiver or main amplifier.

PowerMatch and XBass

ZEN DAC 3 adopts XBass , the newest iteration of iFi's signature analogue EQ.

• XBass Add back the loss bass frequencies from open headphones
• Power Match is a gain boost for hungrier headphones

Power Up, Protect On!

DC offset output voltage has been improved in the ZEN DAC 3. This means less audible clicks while switching functions. ZEN DAC 3 also benefits from input overvoltage protection via the all new USB C port.

IN THE BOX

• ZEN DAC 3
• RCA Cable
• USB-A to USB-C Cable
• 3.5 to 6.3 mm Adapter
• Quick Start Guide
• Instruction Card

SPECIFICATIONS

• Input: USB-C
• Formats: PCM, DSD, MQA, 768kHz, 512, Full Decoder
• DAC: Bit Perfect DSD & DXD DAC by Burr Brown
• Headphone Output: BAL 4.4mm/ UnBAL 6.3mm
• Output Power (RMS):
  • Balanced: 390mW@32; 7.2 V@600
  • Unbalanced: 210mW@32 ; 3.8 V@600
• Output Impedance: <1 (BAL/ UnBAL)
• SNR: 109dB(A) (BAL/UnBAL)
• DNR: 109dB(A) (BAL/UnBAL)
• THD N:
  • Balanced: <0.006% (2.0V @ 600 )
  • Unbalanced: <0.0 06 % (1.27V @ 32 )
• Line Output: BAL 4.4mm/ UnBAL RCA
• Output Power:
  • Balanced: 2V; 6.2V max. (variable); 4.2V fixed
  • Unbalanced: 1V; 3.3V max. (variable); 2.1V fixed
• Output Impedance: <200 BAL; <100 UnBAL
• Frequency Response: 5Hz - 90kHz ( / 3dB)
• Power Consumption: ~2.5W Max Signal
• Dimensions: 158x115x35mm (6.2 x 4.6 x 1.4)
• Weight: 456g (1.0 lbs)
• Warranty period: 12 months

Comparison
