A new Hi-Res USB DAC/Amp with dual ES9219C chip, 3.5mm SE & 4.4mm balanced headphone outputs and amp dedicated power supply.
USB DAC/Amp with Top-Notch Power
The DC07Pro is a new USB DAC/Amp that combines iBasso's extensive experience in USB DAC/Amp development and design elements from their audio players. It utilizes advanced technologies to create a USB DAC/Amp with exceptionally low THD N at 0.000098%. Indeed, the DC07Pro has made significant advancements in its metrics, including dynamic range and output power.
Specs
DAC Chipset
Quad Cirrus Logic CS43131
PCM
up to 32bit/768kHz
DSD
Native DSD up to 512x
Size
2.32"L x 0.93"W x 0.49"D
Weight
23g
Output 4.4mm Balance / 3.5mm Single Ended
Output Power
510mW 510mW @16, THD N | <0.1% 430mW 430mW @32, THD N <0.1% / 210mW 210mW @16, THD N | <0.1% 118mW 118mW @32, THD N <0.1%
Output Voltage
2.8Vrms (low gain), 3.5Vrms (mid gain), 4Vrms (high gain) / 1.4Vrms (low gain), 1.73Vrms (mid gain), 2Vrms (high gain)
THD N
-120.2dB (0.000098%) @1kHz 300 load / -116dB (0.00017%) @1kHz 300 load
SNR Dynamic Range
134dBA / 129dBA
Frequency Response
10Hz-80kHz -0.5dB / 10Hz-75kHz -0.5dB
Noise Floor
0.85V / 0.76V
Crosstalk
142dB / 136dB
