Compact Wireless Music Streaming Amplifier
The POWERNODE EDGE is the perfect segue into just add speakers HiFi for the streaming age, combining streaming sources, control and amplification in a sleek and affordable device.
Meet The PowerNode Edge
JUST ADD SPEAKERS.
All you need to do is connect a pair of passive speakers to experience an incredible all-in-one HiFi solution. Easily connect wired sources, like a TV or turntable, with HDMI eARC or the combo analog/digital input. Add thefor a powerful but compact 2.1 stereo system or even use the POWERNODE EDGE to power the rear channels of a wireless Bluesound surround sound setup. Using the BluOS Controller App, select songs from popular streaming services like Spotify, Tidal, Qobuz, SiriusXM, from your own music library through Apple Airplay2, aptX HD Bluetooth, or even a network-connected drive or USB hard drive.
COMPACT POWER
Bring your speakers to life with the powerful, punchy 2 x 40 watts DirectDigital amplifier in the POWERNODE EDGE, able to handle hi-res, 24 bit/192 kHz files and MQA-encoded tracks with ease. Enjoy clarity in playback of everything from densely-layered heavy metal tracks to whisper-quiet dialogue in movies and TV shows. The POWERNODE EDGE decodes Dolby Digital content on its own and can also be used to power the rear channel speakers of a wireless home theater system.
SPACE SAVING
Your sonic oasis doesnt have to take up all your real estate. With the POWERNODE EDGE, gone are the days of bulky, oversized amplifiers. Comparable in size to the average hardcover book, this small yet mighty HiFi system transforms any space into a high-fidelity haven.
HI-RES FOR EVERY CORNER
The sleek and compact form factor of the POWERNODE EDGE makes it ideal for secondary rooms like offices and back porches. Equip speakers in every corner of your house with power plus streaming and hide the POWERNODE EDGE away from sight in nooks like closets or behind sofas using the included multi-orientation wall-mount bracket.
INTUITIVE CONTROL
Control is always at your fingertips via the BluOS Controller app for iOS, Android, Mac, PC, or using the elegant capacitive touch panel for quick-access controls like Play, Pause, and Volume Up/Down, and Previous/Last Track. The POWERNODE EDGE connects to your home network via Wi-Fi or Ethernet. Hands-free control is possible with voice assistants like Siri, Alexa, and Google Voice. For professional smart home installers, full-feature drivers are available for Lutron, Crestron, RTI, Elan, and other popular control systems.
The POWERNODE EDGE is the perfect segue into just add speakers HiFi for the streaming age, combining streaming sources, control and amplification in a sleek and affordable device.
Meet The PowerNode Edge
JUST ADD SPEAKERS.
All you need to do is connect a pair of passive speakers to experience an incredible all-in-one HiFi solution. Easily connect wired sources, like a TV or turntable, with HDMI eARC or the combo analog/digital input. Add thefor a powerful but compact 2.1 stereo system or even use the POWERNODE EDGE to power the rear channels of a wireless Bluesound surround sound setup. Using the BluOS Controller App, select songs from popular streaming services like Spotify, Tidal, Qobuz, SiriusXM, from your own music library through Apple Airplay2, aptX HD Bluetooth, or even a network-connected drive or USB hard drive.
COMPACT POWER
Bring your speakers to life with the powerful, punchy 2 x 40 watts DirectDigital amplifier in the POWERNODE EDGE, able to handle hi-res, 24 bit/192 kHz files and MQA-encoded tracks with ease. Enjoy clarity in playback of everything from densely-layered heavy metal tracks to whisper-quiet dialogue in movies and TV shows. The POWERNODE EDGE decodes Dolby Digital content on its own and can also be used to power the rear channel speakers of a wireless home theater system.
SPACE SAVING
Your sonic oasis doesnt have to take up all your real estate. With the POWERNODE EDGE, gone are the days of bulky, oversized amplifiers. Comparable in size to the average hardcover book, this small yet mighty HiFi system transforms any space into a high-fidelity haven.
HI-RES FOR EVERY CORNER
The sleek and compact form factor of the POWERNODE EDGE makes it ideal for secondary rooms like offices and back porches. Equip speakers in every corner of your house with power plus streaming and hide the POWERNODE EDGE away from sight in nooks like closets or behind sofas using the included multi-orientation wall-mount bracket.
INTUITIVE CONTROL
Control is always at your fingertips via the BluOS Controller app for iOS, Android, Mac, PC, or using the elegant capacitive touch panel for quick-access controls like Play, Pause, and Volume Up/Down, and Previous/Last Track. The POWERNODE EDGE connects to your home network via Wi-Fi or Ethernet. Hands-free control is possible with voice assistants like Siri, Alexa, and Google Voice. For professional smart home installers, full-feature drivers are available for Lutron, Crestron, RTI, Elan, and other popular control systems.
Specifications:
AUDIO
| Supported Audio File Formats | MP3, AAC, WMA, WMA-L, OGG, ALAC, OPUS |
|---|---|
| Supported Hi-Res Audio File Formats | FLAC, MQA, WAV, AIFF, MPEG-4 SLS |
| Supported Multi-Channel Audio Formats | Dolby Digital |
| Processor | ARM Cortex -A53, Quad-Core, 1.8GHz per core |
| Native Sampling Rates | up to 192 kHz |
| Supported Network File Sharing | Server Messsage Block (SMB) up to 200,000 files |
| Native Sampling Rates | up to 192 kHz |
| Bit Depths | 16 - 24 |
| Signal-to-Noise Ratio | SNR -91dBA THD N, 0.008% |
| DAC | 32-Bit, 384kHz Differential Output design |
| Amplification | DirectDigital |
| Rated Power Output | 40W x 2 (8 Ohms) |
| IHF Dynamic Power | 80W (4 Ohms) / 50W (8 Ohms) |
| Minimum Impedance | 4 Ohms |
SOFTWARE & INTEGRATIONS
| Operating System | BluOS |
|---|---|
| Processor | ARM Cortex -A53, Quad-Core, 1.8GHz per core |
| App Controller Operating Systems | iOS, Android, Windows, macOS |
| Network File Sharing | SMB up to 200,000 track index |
| Album Art Supported | JPG, PNG |
| Internet Radio |
|
| Music Services |
Online Download
Integration Services
|
| Voice Control | Amazon Alexa Skills; Actions on Google |
| 3rd-Party | AirPlay 2 Spotify Connect Tidal Connect Roon Ready |
| Control Systems | Control4, Crestron, URC, RTI, ELAN, Lutron |
GENERAL
| Finish | Black/White; Matte Satin Paint |
|---|---|
| Included Accessories | Black/White; Matte Satin Paint 120V AC Power Cord 230V AC Power Cord Ethernet Cable TOSLINK Optical to 3.5mm Mini Adapter Metal Mounting Bracket Metal Mounting Screw Rubber Mount Attachment Safety/Warranty Guide Quick Setup Guide |
| Max Power Consumption | 210W |
| Storage Environment | -10C to 50C, 20% to 80% relative humidity |
| Operating Environment | '0C to 40C |
| Product Weight | 1.37kg/3.02lbs |
| Product Dimensions | 219 x 44.5 x 193 mm 8.6 x 1.75 x 7.6 in |
| Shipping Weight | 2.62kg/5.78lbs |
| Shipping Dimensions | 300 x 300 x 95 mm 11.8 x 11.8 x 3.74 in |
USER INTERFACE
| Status Indicator | LED |
|---|---|
| Play/Pause Button | Touch LED |
| Volume Control Buttons | Touch LED |
| Previous/Next Track Buttons | Touch LED |
| Preset Buttons | In-App |
CONNECTIONS
| Power Supply | Universal bi-pin AC cord input (100-240AC) |
|---|---|
| Ethernet/LAN | Ethernet RJ45, Gigabit 1000 Mbps |
| Wi-Fi Built In | Wi-Fi 5 (802.11ac), dual-band |
| Bluetooth Quality | Bluetooth 5.0 aptX HD |
| Bluetooth Connectivity | Two-Way (transmit & receive) |
| IR Optical Built In | IR Sensor Built In - front panel with IR Remote Learning |
| IR Input | 3.5mm Jack |
| Optical/Analog Input | Combo - Mini TOSLINK/Stereo 3.5mm |
| HDMI Input | HDMI eARC |
| USB IN | Type A (Fat32 Formatted) |
| Headphone Output | Bluetooth only |
| Subwoofer Output | RCA x 1; Wireless to PULSE SUB |
| Speaker Terminals | 5-Way Binding Post |
